SS Sintered Cartridge
Advantages:
- Made up of super pure Titanium powder/SS Powder(99.6%).
- High aperture rate, excellent structure and good mechanical performance.
- Can work under extreme high or low temperature.
- Good chemical stability & can resist corrosion of acid and alkali, anti- oxidation.
- Can purify or separate all kinds of solid, liquid, air and gas.
Enquiry Call Now
- Made up of super pure Titanium powder/SS Powder(99.6%).
- High aperture rate, excellent structure and good mechanical performance.
- Can work under extreme high or low temperature.
- Good chemical stability & can resist corrosion of acid and alkali, anti- oxidation.
- Can purify or separate all kinds of solid, liquid, air and gas.
- Pharmaceutical grade material.
- Pharmaceutical grade workshops (according to GMP criterion).
-
Strick test before packing
| Medical industry | Decarbonization filtration for transfusion, injection and oral medicine fluid, safety filtration before the end filtration in dilution process |
| Chemical industry | Filtration of dirt and pigment; filtration for returning water in oil fields. |
| Sewage processing industry | Filtration for Ozone after antisepsis & ozone exposure filtration. |
| Food & Beverage industry | Clarification for liquor, beer, mineral water, vegetable oil, soy sauce etc. |
- Filtration Media: Titanium/SS powder sintered
- Core: Nill
- 0-ring/Gasket: EPDM/ VITON/ PTFE
- Effective filtration area (10") > o.4m'.
- Pressure resistance: 5-15 bar.
- Max. working temperature: 280ºc /536°F( wet).
- Max. working pressure: > 6bar ( > 25°C).
- Max. differential pressure: 4.2 bar
- pH value: 1-14.
- Sterilization method: Nil.
| PTT | Length" | Filtration Efficiency | End Cap | Seal Material |
|---|---|---|---|---|
|
Removal Rating
1-120 |
10 = 10" Long | N =Normal | S1 =DOE | S=Silicone |
| 20 = 20" Long | A= Absolute | S3 =Code -7 | E=EPDM* | |
| 30 = 30" Long | S7 = 1" BSP | V=Viton* | ||
| 40 = 40" Long | P=PFA/Viton* | |||
| T =Teflon |
Product Downloads
| No | Title | Download |
|---|---|---|
| 1 | SS Sintered Cartridge | Download PDF |
